OPERATING INSTRUCTIONS Operation Regulating the travelling speed Travelling on level ground Regulate the travelling speed with Ü pedals (112 and 113, Fig. 2-60:) and Ü Switch (71, Fig. 2-61:) to the right (slow gear) All forward/reverse travel movements are possible with this gear. Ü Switch (71, Fig. 2-61:) to the left (fast gear) The excavator can be driven only parallel forwards with this fast gear. The travel gearbox changes automatically into st the 1 gear as soon as another travelling function (e.g. reversing, cornering) is initiated. Change speed range only when the excavator is stationary.
Fig. 2-61:
Travelling uphill and downhill
Read and observe the "Travelling Safety instructions" chapter.
Ü Depress padals (112 and 113, Fig. 2-60:) fully to the limit stop. When travelling downhill, the travel retarder valve acts as a speed limiter. The travel retarder valve works correctly if pedals (112 and 113) are fully depressed down to the limit stop. Fig. 2-60:
Should the travelling speed become too high when travelling downhill release pedals (112 and 113) to stop the excavator.
