POWER TRAIN 365-2814 CASE AS-TRANSMISSION–ALL
WHEEL DRIVE
S/N: LBH1-UP PART OF 359-0393 TRANSMISSION GP-DIRECT DRIVE AN ATTACHMENT
SMCS-3030, 3064 NOTE
B B B B
B B B B B B B B B B B B B B
i04647430
REF NO
GRAPHIC REF
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
PART NAME PART NUMBER
005-0469 121-7398 121-7399 121-7400 121-7401 121-7402 123-8908 123-8910 302-8432 123-8906 6T-9142 6T-9143 6T-9144 6T-9145 6T-9146 6T-9147 6T-9163 6T-9164 6T-9165 6T-9166 7T-2646 7T-3034 104-3288 121-2059 121-2060 121-2061 122-1879
QTY
1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 2 2 2 2 2 1 1 1 1 1 1
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
CUP-BEARING SPACER (70X79.5X2-MM THK) SHIM (0.05-MM THK) SHIM (0.08-MM THK) SHIM (0.18-MM THK) SHIM (0.6-MM THK) CUP-TAPERED ROLLER CUP-TAPERED ROLLER SEAL-LIP TYPE CUP-TAPERED ROLLER SHIM (0.508-MM THK) SHIM (0.381-MM THK) SHIM (0.051-MM THK) SHIM (0.178-MM THK) SHIM (0.127-MM THK) SHIM (0.076-MM THK) SHIM (0.599-MM THK) SHIM (0.178-MM THK) SHIM (0.076-MM THK) SHIM (0.051-MM THK) SPACER (66X79.5X2.02-MM THK) SPACER (56.9X64.5X1.98-MM) SHIM (0.05-MM THK) SHIM (0.08-MM THK) SHIM (0.18-MM THK) SHIM (0.6-MM THK) SPACER (58X67.5X2-MM THK) PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE NUMBER ARE NOT SERVICED SEPARATELY
B-USE AS REQUIRED
250
POWER TRAIN
1 of 2
SEBP5989
