3500 ENGINES
DISASSEMBLY AND ASSEMBLY FRONT BALANCER GROUP (3508)
REMOVE FRONT BALANCER GROUP 1220-11 Tools Needed A B 9S9082 Engine Turning Pinion 1 1P520 Driver Group 1 start by: a) remove front drive housing
1.
Remove the bolts that hold the brackets for shaft (2) to the front of the cylinder block. Disconnect the levers on shaft (2) from the levers on shafts (I) and (3) and remove shaft (2) from the engine.
2.
Use tool (A) to make an alignment of the marks on balancer gear (4) and crank gear (6) according to the rotation of the engine as shown.
3.
Remove the bolts and remove plate (5) from balancer gear (4). Remove balancer gear (4) from the shaft.
4.
Use tool group (A) and a press to remove bearing (7) from balancer gear (4).
5.
Remove shaft (8) from the end of the cylinder block.
6.
Remove crank gear (6) from the end of the crankshaft.
