OPERATOR STATION 229-9084 HEATER & MTG GP-CAB S/N: KGF1-UP; FAL1-UP PART OF 240-5030, 273-5168 HEATER AR-CAB AN ATTACHMENT TYPE 2
SMCS-7304 NOTE
i02911100
REF NO
GRAPHIC REF
1
1
PART NAME PART NUMBER
QTY
235-8873
1
2 1 235-8874 3 1 235-8875 CY 4 1 316-8811 5 1 293-1138 6 1 245-7858 M 8 1 099-2374 9 1 111-4836 10 1 3S-2093 M 11 1 5C-9553 12 1 7X-7729 13 1 8T-0328 14 1 8T-4121 M 15 1 8T-4136 M 16 1 8T-4137 17 1 9X-8256 C-CHANGE FROM PREVIOUS TYPE M-METRIC PART Y-SEPARATE ILLUSTRATION
1 1 1 1 1 2 3 2 1 7 2 3 7 3 1
1652
OPERATOR STATION
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
HARNESS AS-HEATER & AIR COND (CONTROL PANEL SWITCHES) SENSOR-TEMPERATURE (AMBIENT AIR) BRACKET AIR CONDITIONER GP PANEL AS-CONTROL HARNESS AS-HEATER BOLT-SOCKET HEAD (M5X0.8X12-MM) CLIP STRAP-CABLE BOLT (M6X1X16-MM) WASHER (11X25X3-MM THK) WASHER-HARD (5.5X10X1-MM THK) WASHER-HARD (11X21X2.5-MM THK) BOLT (M10X1.5X25-MM) BOLT (M10X1.5X20-MM) WASHER (6.6X12X2-MM THK)
1 of 2
1478
SEBP4874-11
