ELECTRICAL AND STARTING SYSTEM 251-0529 WIRING GP-CAB–1-WAY/2-WAY
FLOW
S/N: KGF1-UP; FAL1-UP PART OF 259-7493, 259-7495 CONTROL AR-AUXILIARY AN ATTACHMENT
SMCS-1408, 7301 NOTE
M M
REF NO
GRAPHIC REF
1 2 3 4 5
1,3 1,2 3 1 1 1 1 1 1 3 3 1
6 7 8 9 M-METRIC PART
438
i02723812 PART NAME PART NUMBER
3S-2093 7K-1181 116-0118 149-5050 251-0598 3S-2093 8T-8737 243-4508 5C-2890 7X-2621 8T-4121 9X-8256
ELECTRICAL AND STARTING SYSTEM
QTY
4 8 2 1 1 6 1 1 1 2 2 1
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
STRAP-CABLE STRAP-CABLE CLIP RELAY (24-VOLT) (1-WAY/2-WAY SOLENOID) HARNESS AS-SOLENOID (1-WAY, 2-WAY FLOW) STRAP-CABLE PLUG-SEAL RECEPTACLE AS-CONNECTOR (6-PIN) NUT (M6X1-THD) BOLT (M10X1.5X12-MM) WASHER-HARD (11X21X2.5-MM THK) WASHER (6.6X12X2-MM THK)
1 of 4
SEBP4874-11
