HYDRAULIC SYSTEM 188-4140 FILTER GP-OIL–HYDRAULIC
RETURN
S/N: KGF1-UP; FAL1-UP PART OF 239-1711 TANK & FILTER GP-HYDRAULIC
SMCS-3004, 4295, 431F, 5068, 5091, 5092 NOTE
REF NO
GRAPHIC REF
Y
1 1 2 1 3 1 4 1 M 5 1 6 1 Y 7 1 8 1 9 1 10 1 M 11 1 12 1 M 13 1 M-METRIC PART Y-SEPARATE ILLUSTRATION
SEBP4874-11
1 of 2
i01518789 PART NAME
PART NUMBER
173-3503 129-8034 123-2003 173-3507 8T-4194 8T-4223 188-4142 173-3510 173-3518 159-7784 6V-4298 8T-0328 8T-6693
QTY
1 1 2 1 8 8 1 1 1 1 4 4 4
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
BASE GP-OIL FILTER (HYDRAULIC) VALVE AS-BYPASS SEAL-O-RING HOUSING AS BOLT (M12X1.75X50-MM) WASHER-HARD (13.5X25.5X3-MM THK) FILTER GP-OIL (HYDRAULIC RETURN) COVER INDICATOR AS (HYDRAULIC RETURN FILTER) SEAL-O-RING BOLT (M5X0.8X16-MM) WASHER-HARD (5.5X10X1-MM THK) SCREW-MACHINE (M5X0.8X16-MM)
HYDRAULIC SYSTEM
