1002-16 Roller Number of upper rollers (per side) ............................................................................................................................... 3 Number of lower rollers (per side)................................................................................................................................ 8 Track belt tension adjuster............................................................................... Grease cylinder type (with cushion spring) Mounting length of spring .................................................................................................................... 1080 mm (42.52 in)
Work Unit Model..................................................................................................................................................Backhoe attachment Standard Boom 7700 mm (303.15 in)
CX700B
Arm (dipper) length
Short boom 6580 mm (259.05 in)
Standard arm
Short arm
Long arm
Super long arm
Short arm
3550 mm (139.76 in)
3020 mm (118.90 in)
4110 mm (161.81 in)
5000 mm (196.85 in)
3020 mm (118.90 in)
Bucket radius Bucket wrist angle
2100 mm (82.68 in)
2200 mm (86.61 in)
175°
170°
Maximum digging radius
13160 mm (518.11 in)
12870 mm (506.69 in)
13650 mm (537.40 in)
14600 mm (574.80 in)
11750 mm (462.60 in)
Maximum digging radius at ground line
12900 mm (507.87 in)
12600 mm (496.06 in)
13400 mm (527.56 in)
14300 mm (562.99 in)
11460 mm (451.18 in)
Maximum digging depth
8400 mm (330.71 in)
7870 mm (309.84 in)
8970 mm (353.15 in)
9850 mm (387.79 in)
7180 mm (282.68 in)
Maximum vertical straight wall digging depth
6870 mm (270.47 in)
6850 mm (269.68 in)
7360 mm (289.76 in)
8630 mm (339.76 in)
5100 mm (200.79 in)
Maximum digging height
11920 mm (469.29 in)
12400 mm (488.19 in)
12040 mm (474.01 in)
12700 mm (500.00 in)
11130 mm (438.19 in)
Maximum dump height
8020 mm (315.75 in)
8330 mm (327.95 in)
8160 mm (321.26 in)
8710 mm (342.91 in)
7040 mm (277.16 in)
Minimum swing radius at front
5810 mm (228.74 in)
5860 mm (230.71 in)
5680 mm (223.62 in)
5700 mm (224.41 in)
5210 mm (205.12 in)
Height for minimum swing radius at front
10040 mm (395.27 in)
9990 mm (393.31 in)
10030 mm (394.88 in)
10030 mm (394.88 in)
9070 mm (357.09 in)
