MAINTENANCE/ADJUSTMENTS
FAN AND ALTERNATOR DRIVE BELTS
IMPORTANT: If the engine runs with a belt slack, the belt can slip in its housing and cause the engine to overheat or the battery to receive insufficient charge.
Tension adjustment
1
2
Tension check
1 CS01M501
Loosen the mounting bolts (1). Use the adjustment screws (2) to move the alternator outwards until belt tension is correct. Tighten the alternator mounting bolts (1). CS98M560
Press the center of the belt, exerting a pressure of about 10 kg. The belt deflection should be about 10 to 15 mm. NOTE: Check that the belts and pullies show no signs of damage or wear. Check that each belt is correctly seated in the pulley grooves. If one belt is stretched, cracked or frayed, replace the set of belts.
179
TRIM THIS EDGE RIGHT PAGE
TRIM THIS EDGE
CD01K007
Template Name: OM_1_col Template Date: 1994_04_29
Visual check ................................................................Every 10 hours or every day Check belt tension......................................................................... Every 250 hours
Alt= to hide template information Alt+ to display template information
Service specifications
