The CX290 is an all hydraulic machine. It consists of an undercarriage fitted with tracks and a turntable bearing which supports the upperstructure frame. The upperstructure frame supports the attachment, at the front end of the machine, plus the engine, hydraulics and cab. When the operator works the controls, the engine-driven variable flow pump delivers hydraulic fluid under pressure to the control valves. The control valves distribute the hydraulic fluid to the various cylinders and hydraulic motors employed. A cooling system and oil cooler keep the fluid temperature down to normal working temperature.
Key to main components Cab/Operator’s compartment Upperstructure Undercarriage Steps Access handles Boom Boom cylinders Dipper Dipper cylinder Backhoe bucket Backhoe bucket cylinder Engine compartment Counterweight Upper rollers Lower rollers Travel reduction gears Idler wheels Tracks Hydraulic reservoir Fuel tank
Template Name: OM_1_col Template Date: 1994_04_29
TRIM THIS EDGE
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Alt= to hide template information Alt+ to display template information
IDENTIFICATION NUMBERS/MACHINE COMPONENTS
13
