LUBRICATION/FILTERS/FLUIDS
GREASING THE HYDRAULIC BREAKER (optional) Template Name: OM_1_col Template Date: 1994_04_29
Greasing intervals
Correct greasing
1.
The tool shank must be well lubricated before installing.
2.
Press the grease gun between 5 to 10 times, at regular intervals, to grease the tool bushing and the tool.
While greasing, the hydraulic breaker must be standing upright resting on the tool to ensure that the grease will penetrate downwards between the tool and the bushing.
3.
Adapt the intervals and the quantity of grease to the wear rate of the tool and to working conditions. This can be anything between every two hours and once a day, depending on the type of material (rock/concrete) being broken.
TRIM THIS EDGE
Insufficient greasing or improper grease may cause :
• •
Abnormal wear of tool bushing and tool Tool breakage
Do not fill the space between the piston and the tool with grease. A lower piston seal failure can result and the hydraulic breaker will eventually leak oil.
Grease points Use the following grease: - EP NLGI grade 2 (for temperate and hot climates) -20°C to +60°C - EP NLGI grade 0 (for cold climates) -40°C to +20°C Every 2 hours
Alt= to hide template information Alt+ to display template information
CP99C004
Tool shank......................................... (1) Tool bushing...................................... (1) NOTE: The figures mentioned in brackets show the number of grease points.
142
