1 - GENERAL INFORMATION
SMIL16MEX0047FB
14. 15. 16. 17. 18. 19. 20. 21. 22. 23.
Bucket control rod Bucket control link Side cutter Bucket cylinder Dipper Dipper cylinder Boom Boom cylinder Swing post Cab/Canopy
24. 25. 26. 27. 28. 29. 30. 31. 32. 33.
1-11
2
Muffler Muffler pipe Counterweight Travel motor Sprocket Upper roller Lower roller Track Idler wheel Dozer blade
