4 - ASSEMBLY
LEIL17WHL2092FB
8
22. Route the hose (18) through the hole in the cooling frame. Install the rubber grommet (3) into the hole and around the hose to prevent the hose rubbing on the cooling frame. 23. Route the hose (15) (from dryer to condenser) through the hole in the cooling frame. Install the rubber grommet (2) into the hole and around the hose to prevent the hose rubbing on the cooling frame. 24. Remove the upper plate from the cooling frame. Discard the plate. 25. Install the seal (H), the seal (L), and the two seals (M) over to cooling frame surfaces. Ensure the seals are compressed by 50% of thickness over the sealing area. 26. Install the air conditioning condenser (20) to the air conditioning condenser plate (19) by means of the four screws (11) and the four washers (23). 27. Install the latch (N) to the air conditioning condenser plate (19) by means of the two screws (P) and the two nuts (Q). 28. Install the air conditioning condenser plate (19) to the cooling frame by means of the two screws (R), the six washers (S), and the two nuts (T). 29. Remove the cap from the end of the hose (18). 30. Lubricate the fitting on the hose (18).
13 EN
