INSTRUMENTS/CONTROLS 5. Oil Pressure Indicator Lamp: When illuminated, this lamp indicates that the engine oil pressure is displayed in the multi-function display (1) in units of PSI of KPa depending on the units selected by the mode switch. 6. Engine Coolant Temperature Indicator Lamp: When illuminated, this lamp indicates that the engine coolant temperature is displayed in the multi-function display (1) in units of Degrees Fahrenheit or Celsius depending on the units selected by the mode switch. 7. Hydraulic Oil Temperature Indicator Lamp: When illuminated, this lamp indicates that the hydraulic oil temperature is displayed in the multi-function display (1) in units of Degrees Fahrenheit or Celsius depending on the units selected by the mode switch.
When illuminated, this lamp indicates the number of hours elapsed since the last time the service interval hourmeter was reset is displayed in the multi-function display (1).
57
TRIM THIS EDGE Bur 9-28727NA RIGHT PAGE
TRIM THIS EDGE
8. Service Interval Hourmeter Indicator Lamp:
