LOADER LIFT ARMS SUPPORT STRUT (90XT)
WARNING: If you service the machine with the loader lift arms raised, always use the cylinder lock support strut to block up the loader lift arms. Failure to follow this procedure can cause serious injury or death if the loader lift arms are lowered by accident. SC018
IMPORTANT: Installing the Support Strut can be performed as a one or two person procedure so that the operator is not exiting the operators compartment under unsupported loader lift arms. Remove the attachment from the loader lift arms before starting this procedure.
Installing the Support Strut 1. Lower the loader lift arms to the ground and stop the engine.
TRIM THIS EDGE
2. Remove the support strut storage pin.
BK97E008
4. Start the engine and slowly raise the loader lift arms until the support stru t is on the lift cylin der rod. Lower the loader lift arms until the support strut makes contact with the lift cylin de r tu b e. S top th e engine.
BK97E005
3. After the pin is removed, lower the support strut onto the lift cylinder.
BK97E007
5. Install the pin in the support strut. 24
