2366 CASE IH AXIAL-FLOW COMBINE (NA) (1/98-8/04) 02-05(03) ROTARY AIR SCREEN PLASTIC DOOR ASSY - ASN JJC0256400
Ссылка Номер детали 1 2 3 4 5 6 7 8 9 10 11 12 13 14 14 15 16 17 17 18 19 20 21 22 23 24 25 26 27 28 30 30 31 29 31 32 33 34 35 36 37 38 39
87430947 87413881 409-7812 231-5148 1329715C1 434-624 495-51053 186646C1 231-5146 87430707 87417094 409-7512 231-5145 87413905 87425804 86985597 495-81116 87413836 87425802 231-5144 87413896 409-7412 485093C1 409-7416 87413830 435624A1 87021006 412506A1 864-8016 87409347 427-4077 409-7416 432-412 87413898 231-5144 87407751 87407737 87408568 444034A2 411-416 86984222 857-10025 306132C1
Кол-во 1 1 1 5 1 1 1 1 1 2 2 20 20 1 1 2 7 1 1 9 1 6 1 1 1 1 4 1 1 1 1 1 1 1 1 1 2 4 1 4 2 3 1
Описание
DOOR, Cooler Access GUIDE, Door Latch BOLT, Hex Flg, 1/2"-13 x 3/4", Serr, 1/2 x 3/4 NUT, Flg, USR, 1/2"-13, HANDLE, BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/2", G5, 3/8 x 1-1/2 WASHER, 1/2", 17/32 x 1 x 1/16 SPACER, 5/8" Tube x 15/16", NUT, Flg, USR, 3/8"-16, SPACER, Hinge HINGE, BOLT, Hex Flg, 5/16"-18 x 3/4", Serr, NUT, Flg, USR, 5/16"-18, HINGE, , BTW JJC0255700 & JJC0256341 HINGE, Hinge Support, ASN JJC0256400 WASHER, Special WASHER, .344" x 1" x .060", 11/32 x 1 x 1/16 COVER, , BTW JJC0255700 & JJC0256341 COVER, COVER Door Hinge, Shown, ASN JJC0256400 NUT, Flg, USR, 1/4"-20, (5) BRACKET, Blockoff Assy BOLT, Hex Flg, 1/4"-20 x 3/4", Serr, 1/4 x 3/4 CLAMP, BOLT, Hex Flg, 1/4"-20 x 1", Serr, SUPPORT, MOTOR, HYDRAULIC, Rotary Screen BOLT, Hex Flg, M10 x 16, 10.9, Full Thd, M10 x 16; 10.9 HUB, SCREW, Hex Soc Hd, M8 x 16, 8.8, SUPPORT, Inner Baffle PIN, CLEVIS, 1/4" x .770", , BSN JJC0256341 BOLT, Hex Flg, 1/4"-20 x 1", Serr, , ASN JJC0256400 PIN, SPLIT (COTTER), 1/16" x 3/4", , BSN JJC0256341 SUPPORT, NUT, Flg, USR, 1/4"-20, , ASN JJC0256400 BRACKET, BRACKET, BEARING, BALL, Roller SUPPORT, Roller BOLT, CARRIAGE, Short NK, 1/4"-20 x 1", G2, 1/4 x 1 PAD, BOLT, Hex Flg, M10 x 25, 10.9, Full Thd, M10 x 25; 10.9 STRAP, CABLE, .30" x 14.5",
