Maintenance Safety rules for servicing work Valid from serial number 3 300 000-
Date 2006-06-19
Order number 232319-040
• If welding or grinding is to be carried out, remove at least 100 mm of paint from around the welding/grinding area using sanding equipment or paint stripper. WARNING! Harmful gases Heated paint gives off harmful gases. Remove 100 mm of paint from around the working area.
WARNING! Risk of cuts, risk of crushing There is a RISK OF CUTS when the pallet truck is lifted by hand from the forks and end plate. There is a RISK OF CRUSHING when the pallet truck is lifted by hand from the chassis by the hydraulics. WORK GLOVES must be used for lifting the pallet truck by hand. Bad blocking under a truck can collapse. The truck must always be secured for repairs.
• When fitting/removing locking rings, there is a risk that the locking ring may come loose from the locking ring pliers and cause damage. • When hammering in or out, spiral pins can bounce and cause damage. Be careful when fitting/removing spiral pins. • When fitting/removing springs, they can spring out of position and cause damage.
2.2.1 Observe the following for servicing and maintenance • Always replace removed spiral pins. Never reuse spiral pins, as they may have lost their flexibility when removed. • Replace lock rings, o-rings, collars, washers, seals, etc. if they look like they have been damaged when removed. • Always bleed the hydraulics when components have been replaced. See section “4.11 Changing the oil”. • Always check that neutral, lifting and lowering modes function after work on the hydraulics. Some adjustment may be necessary. • Check that there is no leakage after work on the hydraulics. • Watch for any oil spills when components in the hydraulics have been replaced. It may be useful to have the driver’s manual and spare parts catalogue to hand.
4
Service Manual
LHM230, LHM300
© BT Europe AB
