Portable Pressure Washer Familiarization and Troubleshooting Guide Section 4 • Small Frame Electric Pump
Exploded View
A typical small frame electric pump is depicted in exploded view in Figure 4.2.
Figure 4.2 — Small Frame Electric Pump (exploded view)
Item
Torque Value
6
15-17 ft-lbs
19
7-9 ft-lbs
28
9-12 ft-lbs
33
9-12 ft-lbs
40
2-4 ft-lbs
41
2-4 ft-lbs
48
10-12 ft-lbs
54
Brass: 15-23 ft-lbs Nylon: 10-12 ft-lbs
57
20-30 in-lbs
