CONTROL FUNCTIONS (CONT’D) Application Interface Outline (Cont’d) Constant speed by the auto deceleration mode can be temporarily released by acceleration use even the operation oil pressure switch is: APP-IP4=OFF, as shown in [Figure 10-40-38]. The operated accelerator’s target speed is followed during the deceleration release (optional).
Figure 10-40-38
Deceleration release by acceleration operation (optional) Deceleration permission APP-IP6
Engine start
Operation oil pressure
Non-operational
APP-IP4
Release
Release
Acceleration Operation
4s later
Constant speed
4s later
Constant speed
4s later
Constant speed
By APP-IP3 terminal input
10-40-35 83 of 182
