CONTROL FUNCTIONS (CONT’D) Application Interface Outline (Cont’d) Utilizing features 1 and 2 above permits establishing a remote (auto) start/stop system that can be operated through an external sequence. See [Figure 10-40-30] for details. In the figure, a machine start recognition signal (E8) is given from an external control device in place of the key switch.
Figure 10-40-30 External controller (Ex.: PLC) 12V Run signal 12V
Start signal
Run signal • Goes off when the engine stops. Start signal • Must be tuned off when it is detected that the engine has started. • Must be turned off within 160 seconds if it is not detected that the engine has started.
External switch APP-IP1 E24 E39 E40
CAN communication
ECU
Relay (NO)
E20 APP-OP1 E8 Engine start recognition
S
Starter
B
Battery
The engine run signal goes on at engine start and goes off at engine stop. The start signal must be turned off within 160 seconds as a guideline. Otherwise, the starter tries to start the engine repeatedly in intervals of 30 seconds when the engine may not be able to start for some reason.
