PRECAUTIONS ON THE USE OF ELECTRONIC CONTROL COMPONENTS (CONT’D) Engine Diagnosis Tool Figure 10-10-3
DEUTSCH DTM06-06S-E007 Batt.12V
NC
CANH
NC
CANL
GND
Mating connector (of the service tool) DEUTSCH DTM04-06P-E003 Install the connector shown in [Figure 10-10-3] at a convenient position on the intended machine in order to permit connection of the Bobcat genuine engine diagnosis tool.
