Removing the LCD Brackets and FPC Cable 1. See “Removing the LCD Panel” on page 79. 2. Turn the LCD panel over on a clean surface. Carefully lift the adhesive tape securing the cable connector to the LCD Panel.
3. Hold the adhesive tape clear of the LCD Panel and disconnect the LCD cable as shown.
4. Remove the four securing screws (two each side) from the LCD Brackets.
Step LCD Brackets
Chapter 3
Size M2*3
Quantity
Screw Type
4
81
