Removing the LCD Bezel 1. See “Removing the LCD Module” on page 71. 2. Remove the four screw caps and screws from the LCD Bezel. NOTE: The two center screw caps at the top of the bezel are for protection only.
Step LCD Bezel
Size M2*4
Quantity
Screw Type
4
3. Starting from the inside right edge, pry the bezel away from the panel. Continue moving along the top, prying the bezel away from the LCD Module. If necessary, use a plastic pry to release the corners of the bezel.
