Removing the Bluetooth Module 1. See “Removing the Upper Cover” on page 51. 2. Remove the Bluetooth Module cable from the cable channel. Ensure that the cable is free from all cable clips.
3. Lift the Bluetooth Module, left side first, to remove it from the Upper Cover. NOTE: The Bluetooth Module is held in place by a single screw (M2*3) on some models.
4. Disconnect the cable from the Bluetooth Module as shown.
