Replacing the LCD Panel 1. Place the Microphone Module in to the LCD Module and press down to secure the adhesive holding it in place.
2. Run the Microphone cable down the side of the LCD Module as shown, using all available adhesive and cable clips.
3. Replace the LCD Panel top edge first as shown. Lower the Panel in to the LCD Module, ensuring the LCD cables are not trapped between the panel and the casing.
