Bottom View
Item
158
Description
Item
Description
PCN1
AC-IN Connector
JLINE1
LINE IN JACK
JRJ45
RJ45 Connector
JMIC1
MIC IN JACK
JCRT1
CRT Connector
JHP1
Head-Phone Jack
JP32
Fan Connector
JCPU1
CPU Socket
JMXM2
MXM Connector
JDIMM2
Memory DIMM2 Connector
JHDMI1
HDMI Connector
JDIMM1
Memory DIMM1 Connector
JESATA1
ESATA Connector
PJP1
Battery Connector
JUSB2
USB Connector
JSATA1
HDD Connector
JUSB3
USB Connector
JSATA2
ODD Connector
