Hardware Specifications and Configurations Processor Item
Specification
CPU
• • • •
AMD Athlon64 Dual-Core Process, Cache 1MB, TK42 AMD Athlon64 Process, 2.2GHz, Cache 256KB, TF38 AMD Athlon64 Process, 2.0GHz, Cache 256KB, TF36 AMD Athlon64 Process, 1.6GHz, Cache 512KB, TF20
Type
AMD Athlon64 Dual-Core Mobile CPU
Core Logic
• AMDRS780MN • AMDSB710 • Integrated VGA solution
CPU Package
Micro uPGA-638 Package
Power
45W
On-die Cache
Up to 1MB L2 cache
Front Side Bus
667/800/1066MHz
Processor Specifications Item
CPU Speed
AATF20
1.6GHz
1
638 MHz
AATK42
1.6GHz
2
638 MHz
Cores
Bus Speed
Mfg Tech
65 nm
Cache Size
Package
Core Voltage
Acer P/N
512K
TF20 PGA
15W
KC.ATF02.200
1M
TK42
20W
KC.ATK02.420
CPU Fan True Value Table Fan On Temp (°C)
Fan Speed (rpm)
SPL Spec (dBA)
55
3000
28
60
3300
31
65
3700
34
75
4100
37
80
4500
40
•
Throttling 50%: On=90°C, Off=80°C
•
OS Shutdown: 95°C
•
H/W Shutdown: 92°C
Northbridge Item
Specification
Chipset
ATI RS780MN
Package
465 BGA
Southbridge Item
Specification
Chipset
ATI SB710
Package
549 BGA
BIOS Item
Specification
BIOS vendor
Phoenix BIOS
BIOS Version
V0.11T04
Chapter 1
17
