Power The Power screen allows the user to configure CPU and power management options.
Information
Main
InsydeH20 Setup Utility Advanced Security Power Boot
Rev 3.5 Exit Item Specific Help
XAdvanced CPU Control XPlatform Power Management XBreak Event ACPI S3: Wake on PME Wake on Modem Ring Quickly S4 Resume Auto Wake on S5
F1 Help ESC Exit
These items control various CPU paramaters. [Enabled] [Enabled] [Enabled] [Disabled] [Disabled]
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter SelectXSubmenu
F9 Setup Default F10 Save and Exit
The table below describes the items, menus, and submenus in this screen. Settings in boldface are the default and suggested parameter settings. Parameter Advanced CPU Control
38
Description Enter the Advanced CPU Control menu.
Submenu Items • • • • • • • • • • • • • • • • • • • • • • •
P-States (IST) Boot performance mode Thermal Mode CMP Support Use XD capability VT Support SMRR Support C-States Enhanced C-States C-State Pop Up Mode C-State Pop Down Mode C4 Exit Timing Mode DeepC4 Hard C4E Enable C6 EMTTM Bi-directional PROCHOT# Dynamic FSB Switching Turbo Mode ACPI 3.0 T-States DTS DTS Calibration Thermal Trip Points Setting (Fan On Temp., Throttle On Temp.) Chapter 2
