Hardware Specifications and Configurations Processor Item
Specification
CPU Type
Intel Core 2 Duo T6400 PGA 2.0G 3M 800 35W r-0 (see Processor Specification below for more information)
Core Logic
Intel Cantiga GM—800/1066MHz FSB supported Intel Cantiga PM—800/1066MHz FSB supported ICH9-M
CPU Package
Micro uPGA-478 Package
CPU Core Voltage
Refer to table below
Processor Specifications Processor #
CPU Speed
Bus Speed
Cores
Mfg Tech
Cache Size
Package
Core Voltage
Acer P/N
T1600
1.66 GHz
2
667
1 MB
uPGA
KC.16001.CMT
T6400
2.0 GHz
2
800
3 MB
uPGA
KC.64001.DTP
T6600
2.2 GHz
2
800
2 MB
uPGA
KC.66001.DTP
P7450
2.13 GHz
2
1066
3 MB
uPGA
KC.74501.DPP
T4200
2.4 GHz
2
800
2 MB
uPGA
KC.42001.DTP
System Board Major Chips Item
Specifications
Core logic
Intel Cantiga PM45 / GM45 (667/800/1066MHz FSB supported) ICH9-M
VGA
•
NB10MGE1-512MB-DDR3
•
Integrated VGA solution for CANTIGA GM / On board VGA card for CANTIGA PM
LAN
ATHEROS AR8121 for Giga LAN
Media Card Reader
JMICRON JMB385
Audio Codec
REALTEK ALC888S-VC for High Definition Audio Codec with Dolby Digital Live
CPU Fan True Value Table CPU Temperature (°C) Core1
Fan Speed (rpm)
Core 2
SPL Spec (dBA)
50
50
-
-
66
66
3200
31
74
74
3500
34
85
85
3900
37
100
100
4300
40
•
Throttling 50%: On =100°C; Off=90°C
•
OS Shut down: 105°C
•
H/W Shut down: 96°C
BIOS ROM Item BIOS Vendor
18
Specification Insyde H20
