Jumper and Connector Locations Top View
1
SW1
Switch
7
BLUE1
Bluetooth Cable Connector
2
LEDB1
LED Board Cable Connector
8
U39
LAN Connector: RTL8100CL
3
KB1
Keyboard Connector
9
RTC1
RTC Battery Connector
4
TPAD1
Touchpad Cable Connector
10
U40
Keyboard Controller: ENE CB1410QF
5
LCD1
LCD Cable Connector
11
SPKR1
Speaker Set Cable Connector
6
LAUNCH1
Launch Board Cable Connector
