Chapter 2
System Utilities BIOS Setup Utility The BIOS Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/ Output System). Your computer is already properly configured and optimized, and you do not need to run this utility. However, if you encounter configuration problems, you may need to run Setup. Please also refer to Chapter 4 Troubleshooting when problem arises. To activate the BIOS Utility, press m during POST (when “Press <F2> to enter Setup” message is prompted on the bottom of screen). Press m to enter setup. The default parameter of F12 Boot Menu is set to “disabled”. If you want to change boot device without entering BIOS Setup Utility, please set the parameter to “enabled”. Press <F12> during POST to enter multi-boot menu. In this menu, user can change boot device without entering BIOS SETUP Utility.
PhoenixBIOS Setup Utility Main
Information
Security
Boot
Exit
Intel (R) Pentium (R) M processor 1.86GHz CPU Type : 1866MHz CPU Speed : IDE1 Model Name : TOSHIBA MK8025GAS - (PM) IDE1 Serial Number : None PIONEER DVD-RW DVR-K15RA - (PS) IDE2 Model Name : IDE2 Serial Number : None System BIOS Ver: V0.06A 1277 VGA BIOS Ver 07.07 KBC Ver xxxxxxxxxxxxxxxxxxxxxx Serial Number Asset Tag Number Produce Name
N/A Aspire 3610
Manufacturer Name: UUID:
Acer xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
F1
Help
Esc Exit
Chapter 2
↑ ↓ ←→
22 Byte 32 Byte 16 Byte 16 Byte 32 Byte
Select Item
F5/F6 Change Values
F9 Setup Defaults
Select Menu
Enter Select 4 Sub- Menu
F10 Save and Exit
29
