SHIFT SELECTOR CABLE LINKAGE

3–1.

Section III

SHIFT SELECTOR AND CABLE/LINKAGE

a. Adjustment. The transmission internal detent lever and spring must dictate the position of the manual selector valve in the control valve body. Any customer-furnished shift selector system must be designed and adjusted to accomplish this positioning. The shift selector must move the internal detent lever from position to position and not interfere with the ability of the internal detent spring to position the manual selector valve. When the internal detent spring is in the center of a detent lever position, the shift selector handle should be in the center of the shift selector gate (refer to Figure 3–1). Follow the procedure below to adjust the shift selector cable at the shift lever on the transmission.

R

“Gates” in shift selector permit transmission detent to determine actual selector shaft orientation

N D 3 2 1

V05806.01.00

Figure 3–1. Proper Shift Selector Cable Adjustment 1. With the engine off, set the parking brake and block the wheels to prevent vehicle movement. 2. Dettach the cable pivot from the transmission selector lever (refer to Figure 3–2). 3. Place both the shift selector and the transmission selector shaft in the N (Neutral) position.

35
