Chapter 4 - Part Name (5) Emergency stop button Push down the emergency stop button to its "OFF" position to stop all functions. Pull up the emergency stop button to its "ON" position to operate the machine. (6) Overload warning light / Tilt light / System failure light • Overload warning light: When the platform is overloaded, this light blinks, the alarm buzzer sounds and all of the functions are disabled. • Tilt light: When the machine is on a slope, this light goes on, the alarm buzzer sounds and platform lift up function is disabled. • System failure light: This light goes on or blinks, in the event of a computer control system failure. (7) Key switch for Upper control / Off / Lower control selection Turn the key switch to the left and the upper controls will operate. Turn the key switch to center position and the machine will be off. Turn the key switch to the right and the lower controls will operate. (8) Battery level indicator / Hour meter • This indicator displays the battery charge level. • The hour meter works only when the machine is in motion.
15
