Jumper and Connector Locations Top View
TravelMate 8371/8331 M/B layout and connector location TOP view No.
Chapter 5
Name
Description
1
CN1
CCD cable CNTR
2
CN2
MMB cable CNTR
3
CN3
LVDS cable CNTR
4
CN4
Keyboard CNTR
5
CN5
Touch Pad FFC CNTR
6
CN6
SSD cable CNTR
7
CN7
Card reader CNTR
8
CN8
BT cable CNTR
9
CN15
Fan cable CNTR
10
CN21
Audio board CNTR
