Bottom View
Bottom view No.
6
Name
Description
11
CN9
Battery CNTR
12
CN10
PCI-E socket
13
CN11
SIM card socket
14
CN12
PCI-E socket
15
CN13
Power cable CNTR
16
CN14
LVDS cable CNTR
17
CN16
DIMM socket
18
CN17
DIMM socket
19
CN19
HDD socket
20
CN20
USB board CNTR
21
U18
South Bridge
22
U14
North Bridge
Chapter 1
