8.
See “Removing the Middle Cover” on page 64.
9.
See “Removing the Keyboard” on page 65.
10. See “Removing the LCD Module” on page 66. 11. See “Separating the Upper Case from the Lower Case” on page 70. 12. Remove the screw (G) on the LED indicators board.
Step
Size (Quantity)
Color
Torque
1
M2 x L3 (1)
Silver
1.6 kgf-cm
13. Turn the LED board over, then detach the LED cable from the board.
14. Disconnect the LED board cable from the board, then remove the board.
Remove the Daughter Board
74
1.
See “Removing the Battery Pack” on page 51.
2.
See “Removing the SD Dummy Card” on page 51.
3.
See “Removing the Express Dummy Card” on page 52.
4.
See “Removing the Lower Cover” on page 53.
5.
See “Removing the Fan Module” on page 60.
6.
See “Removing the CPU Heatsink Module” on page 61. Chapter 3
