Chapter 1
System Specification Features Below is a brief summary of the computer’s many feature:
Platform T
T
Intel® Pentium® processor T2310/T2330 (1 MB L2 cache, 1.46/1.60 GHz, 533 MHz FSB) or Celeron® processor 530/540/550 (1 MB L2 cache, 1.73/1.86/2 GHz, 533 MHz FSB) supporting Intel 64 architecture Mobile Intel GL960 Express chipset
Display and Graphics T
14.1" WXGA high brightness (200-nits) Acer CrystalBrite™ TFT LCD, 1280 x 800 pixel resolution, 16 ms response time, supporting simultaneous multi-window viewing via Acer GridVista™
T
Mobile Intel GL960 Express Chipset with integrated 3D graphics, featuring Intel Graphics Media Accelerator (GMA) X3100 with up to 358 MB of Intel Dynamic Video Memory Technology 4.0 (8 MB of dedicated system memory, up to 350 MB of shared system memory), supporting Microsoft DirectX® 9 and DirectX 10
T
Dual independent display support
T
16.7 million colors
T
MEPG-2/DVD hardware-assisted capability (acceleration)
T
S-video/TV-out (NTSC/PAL) support
T
Acer Arcade™ featuring Acer CinemaVision™ and Acer ClearVision™ technologies
Storage Subsystem T
80/120/160 GB or larger hard disk drive
T
DVD-Super Multi double-layer drive or DVD/CD-RW combo drive
Audio T
Two built-in Acer 3D Sonic stereo speakers
T
Intel High Definition Audio support
T
MS-Sound compatible
T
Built-in microphone
Input Devices T
88-/89-/93-key keyboard, with inverted "T" cursor layout; 2.5 mm (minimum) key travel
T
Seamless touchpad
T
T
Chapter 1
12 function keys, four cursor keys, two Windows® keys, hotkey controls, embedded numeric keypad, international language support, independent US and Euro dollar sign keys, media control keys Easy-launch buttons: Empowering key, WLAN
1
