Chapter 1
System Specification Features Below is a brief summary of the computer’s many feature:
Platform T
Intel® Core™2 Duo Mobile Processor T7200/T7400/T7600 (4 MB L2 cache, 2/2.16/2.33 GHz, 667 MHz FSB), T5300/T5500/T5600 (2 MB L2 cache, 1.73/1.66/1.83 GHz, 667 MHz FSB), T2350/2450 (2 MB L2 cache, 1.86/2 GHz), and Celeron M 520/530(1 MB L2 cache, 1.6/1.73 GHz supporting Intel 64 architecture
T
Mobile Intel PM945 Express chipset
T
Intel PRO/Wireless 3945ABG (dual-band tri-mode 802.11a/b/g) or 3945BG (dual-mode 802.11b/g) Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology
Display and Graphics T
14.1" WXGA high brightness (200-nits) Acer CrystalBrite™ TFT LCD, 1280 x 800 pixel resolution, supporting simultaneous multi-window viewing via Acer GridVista™
T
ATI Mobility™ Radeon® HD2300 with up to 896 MB of HyperMemory™ (128 MB of dedicated GDDR2 VRAM, up to 768 MB of shared memory) supporting Microsoft® DirectX® 9 and PCI Express®
T
Dual independent display support
T
16.7 million colors
T
MPEG-2/DVD hardware-assisted capability (full decode)
T
S-video/TV-out (NTSC/PAL) support
T
Acer Arcade™ featuring Acer CinemaVision™ and Acer ClearVision™ technologies
Storage Subsystem T
80/120/160 GB or larger hard disk drive
T
DVD-Super Multi double-layer drive
T
5-in-1 card reader supporting Secure Digital (SD), MultiMediaCard (MMC), Memory Stick® (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Audio T
Dolby®-certified surround sound system with two built-in stereo speakers
T
Dolby Home Theater audio enhancement featuring Dolby Digital, Dolby Digital Live, Dolby PRO LOGIC® II, Dolby Digital Stereo Creator, Dolby Headphone and Dolby Virtual Speaker technologies
T
Intel High Definition Audio support
T
S/PDIF (Sony/Philips Digital Interface) support for digital speakers
T
MS-Sound compatible
T
Acer PureZone technology with two built-in stereo microphones featuring beam forming, echo cancellation, and noise suppression technologies
Chapter 1
1
