3.
See “Installing the LCD Brackets” on page 95.
4.
See “Installing the 15” TFT LCD” on page 96.
5.
Connect the inverter cable to the inverter board. Connect the inverter board to the LCD.
NOTE: Please arrange the LCD inverter cable well to the LCD panel as the picture below shows when you reassemble the LCD module.
6.
Secure the inverter board with one screw.
Installing the LCD Bezel
81
1.
See “Installing the LCD Hinges” on page 95.
2.
See “Installing the LCD Coaxial Cable” on page 95.
3.
See “Installing the LCD Brackets” on page 95.
4.
See “Installing the 15” TFT LCD” on page 96.
5.
See “Installing the Inverter Board (15” LCD)” on page 96.
6.
Attach the LCD bezel to the LCD module.
Aspire 1610
