Removing the Modem Board 1.
See “Removing the Battery” on page 48.
2.
To remove the modem board, first remove the screw from the modem cover.
3.
Remove the modem cover from the machine.
4.
Remove two screws from the modem board as shown. Please remove the screws according to the number on the picture indicate.
5.
Then remove the modem board from the main unit carefully by using a plastic bladed screw driver.
6.
Disconnect the modem cable from the modem board, then remove the modem board.
Chapter 3
50
