33 - Electrical System
57 - Electronic Diagnostic 90 - Fault Codes
Error Code K0331 K4109 K4107 K0324 K4114 K4112 K0332 K4119 K4117 K0323 K4123 K4122 K0325 K4128 K4127 K0753 K4131 K4132 K4219 K4140 K4141 K4142 K4143 K4144 K4152 K4735 K4736 K4157 K4155 K4156 K4158 K4740 K4741 K4742 K4743 K4051 K4052
33 - 348
Description Engine injector cylinder #2, Current below normal: Open circuit Engine injector cylinder #2, Calibration value missing Engine injector cylinder #2, Short circuit Engine injector cylinder #3, Current below normal: Open circuit Engine injector cylinder #3, Calibration value missing Engine injector cylinder #3, Short circuit Engine injector cylinder #4, Current below normal: Open circuit Engine injector cylinder #4, Calibration value missing Engine injector cylinder #4, Short circuit Engine injector cylinder #5, Current below normal: Open circuit Engine injector cylinder #5, Calibration value missing Engine injector cylinder #5, Short circuit Engine injector cylinder #6, Current below normal: Open circuit Engine injector cylinder #6, Calibration value missing Engine injector cylinder #6, Short circuit Number and/or position of the camshaft pulses implausible - disturbed signal Signal deviation between crankshaft and camshaft too large Cam speed sensor signal missing Speed Control (TSC1) timeout MPROP control, High side short circuit to HIGH SOURCE MPROP control Low side short circuit to GROUND MPROP control Low side short circuit to HIGH SOURCE MPROP control High side short circuit to GROUND MPROP control Open circuit MPROP control Power stage over temperature Intake manifold 1 air temperature sensor voltage above normal or open circuit Intake manifold 1 air temperature sensor voltage below normal Engine ECU over temperature HIGH ALARM ECU temperature sensor voltage above normal or open circuit ECU temperature sensor voltage below normal Engine ECU over temperature HIGH, ALARM 2 WG Actuator 1 position deviation Wastegate Actuator 1 motor not powered due fault condition (ERROR 5) Wastegate Actuator 1 torque limited Wastegate Actuator 1 calibration error Rail pressure Leakage detected at load condition Rail pressure Leakage detected at low idle
9813/3600-3
33 - 348
