"Hexashift" Description 64 O-ring.
77 Screw.
88 Elastic washers.
65 O-ring.
78 Cover.
89 Ball bearing.
66 Multiplier housing.
79 Shaft.
90 Clutch "F" housing.
67 Screw.
80 O-ring.
91 Friction washer.
68 Screw.
81 Clutch, brake "F" piston, "E" brake.
92 Washer.
69 Ball bearing.
82 Spring.
93 O-ring.
70 Third epicyclic gear set ring gear.
83 Clutch "F" discs.
94 Multiplier cover.
71 Bronze bush.
84 Clutch "F" backplates.
95 Screw.
72 Ball bearing.
85 Brake "E" discs.
96 Lip seal.
73 Third epicyclic gear set planet carrier.
86 Brake "E" backplate.
97 Triple spring washer.
74 Third epicyclic gear set planet gear.
87 Clutch, brake "F" bearing plate, "E" brake.
99 Panel fastener.
75 Third epicyclic gear set sun gear.
98 Plate.
76 Locking ring.
Axion 850-810 – 10.2010 – GB
B2.7
