"Hexashift" Description 1 Clutch bearing.
34 Ball bearing.
67 Screw.
2 Ball bearing with sealed side.
35 Locking ring.
68 Screw.
3 Locking ring.
36 First epicyclic gear set sun gear.
69 Ball bearing.
4 Blanking plate.
37 Screw.
70 Third epicyclic gear set ring gear.
5 Screw.
38 First epicyclic gear set planet carrier.
71 Bronze bush.
6 Screw.
39 First epicyclic gear set planet gear.
72 Ball bearing.
7 Additional multiplier cover.
40 Retaining ring.
73 Third epicyclic gear set planet carrier.
8 Screw.
41 Retaining ring.
74 Third epicyclic gear set planet gear.
9 Friction washer.
42 First epicyclic gear set ring gear.
75 Third epicyclic gear set sun gear.
10 Clutch "D" housing.
43 Ball bearing.
76 Locking ring.
11 Spring washer.
44 Spring washer.
77 Screw.
12 Brake "C" discs.
45 Screw.
78 Cover.
13 Clutch, brake "D" bearing plate, "C" brake.
46 Ring gear holder.
79 Shaft.
47 Locating pin.
80 O-ring.
14 Brake "C" backplate.
48 Additional multiplier housing.
81 Clutch, brake "F" piston, "E" brake.
15 Clutch "D" discs.
49 Locating pin.
82 Spring.
16 Clutch "D" backplates.
50 O-ring.
83 Clutch "F" discs.
17 Spring.
51 Clutch, brake "B" piston, "A" brake.
84 Clutch "F" backplates.
18 Clutch, brake "D" piston, "C" brake.
52 Spring.
85 Brake "E" discs.
19 O-rings.
53 Clutch "B" splined hub.
86 Brake "E" backplate.
20 Cover.
54 Shaft.
21 Screw.
55 Clutch "B" discs.
87 Clutch, brake "F" bearing plate, "E" brake.
22 Clutch "D" splined hub.
56 Clutch "B" backplates.
88 Elastic washers.
23 Second epicyclic gear set sun gear.
57 Brake "A" discs.
89 Ball bearing.
24 Screw.
58 Brake "A" backplate.
90 Clutch "F" housing.
25 Spring washer.
59 Clutch, brake "B" bearing plate, "A" brake.
91 Friction washer.
26 Locking ring. 27 Ball bearing.
60 Spring washer.
93 O-ring.
28 Lubricating oil deflector.
61 Clutch "B" housing.
94 Multiplier cover.
29 Second epicyclic gear set planet carrier.
62 Friction washer.
95 Screw.
30 Second epicyclic gear set planet gear.
63 Washer.
96 Lip seal.
31 Screw.
64 O-ring.
97 Triple spring washer.
32 Second epicyclic gear set ring gear.
65 O-ring.
98 Plate.
33 Lubrication ring.
66 Multiplier housing.
99 Panel fastener.
Axion 850-810 – 10.2010 – GB
92 Washer.
B2.5
