Electronic architecture “C.I.S.” Technical description The electronic architecture is made of 3 communication networks and maximum 19 modules.
Communication networks Name
Functions
Type
Establishment of communication between the following modules DBD : Dashboard and CAN network communication module. EXT : External functions module. HYD : Hydraulic module. MFA : Multifunction armrest module. WLP : Working lights module.
Owner
Hydraulic CAN bus
Establishment of communication between the following modules HYD : Hydraulic module. 1 valve : Electrodistributor module n°1. 2 valve : Electrodistributor module n°2.
Owner
Powertrain CAN bus
Establishment of communication between the following modules DBD : Dashboard and CAN network communication module. DSP : Gearbox display module. ENG : Engine module. REH : Rear lifting module. SFA :Suspended front axle module. TR1 : Transmission module. TR2 : Transmission module. TR3 : Transmission module.
J1939
Establishment of communication between the following modules ENG : Engine module. VGT : Turbocharger module.
Owner
Claas vehicle CAN bus
Turbo serial bus
Arion 640-510 – 06.2008 – GB
13
