“REVERSHIFT” Hydraulic part of the lubrication Circuit 60 l/min or 98 l/min 6 11
A
9
5 bar
12
8 7a B
7b
7
3 bar
7c 7d
7 394msm83
Fig. 17
Description 6 Lubrication feeder.
8 Clutch lubrication:
7 Rear axle lubrication.
– "Quadrishift".
7a Lubrication of:
– Reverter rear under torque.
– Upper range shaft.
9 Lubrication of:
– Front power take-off bearing.
– Ranges lower shaft.
– Power take-off clutch.
– Reverse countershaft.
7b Tapered torque lubrication.
– Clutch before reverter under torque.
7c Rear power take-off lubrication.
11 Cooler.
7d Brake lubrication.
12 "By-pass" valve.
Circuit “A”
Circuit “B”
Excedent 20 bar circuit.
Lubrication pump + excedent high pressure circuit.
Arion 630-610 C – 09.2008 – GB
B2.15
