“REVERSHIFT” Law for passing under torque “Quadrishift” To prevent jolting when changing gears under torque, the reverter is made to slip. y
1
5
20 bar
2
4
P2
3
x 60cmsm78
Fig. 16
Description 1 “Quadrishift” gear change request.
5 Locking phase (maximum pressure in the clutch).
2 Skidding phase.
P2 Locking pressure.
3 “Quadrishift” gear change performed.
x Time.
4 Pressure build-up phase in the clutch.
y Pressure.
Electronic protection When the oil temperature exceeds 105 °C, the indicator is lit on the instrument panel.
B2.14
Arion 630-610 C – 09.2008 – GB
