Operation
Starting process Starting
control via a relay: Before starting, make sure that nobody is standing in the immediate vicinity of the engine or work machine. After repair work: Check that all guards have been replaced and that all tools have been removed from the engine. When starting with the flame glow plug/ glow plug/heating flange system do not use any other starting aid (e.g. injection with start pilot). Risk of accident! If the engine fails to fire and the error lamp lights, the electronic engine control has activated the start lock to protect the engine. The start lock is released by switching off the system with the ignition key for about 30 seconds. Do not actuate the starter for more than 20 seconds. If the engine does not start up, wait for one minute and then repeat the starting process. If the engine does not start up after two attempts, determine the cause as per fault table ( 59). Do not run up the engine immediately to high idling speed / full load operation from cold. Disconnect the engine by uncoupling devices to be driven where possible.
P 0
● the maximum start duration is limited. ● the pause between two start attempts is specified. – the start is then continued automatically
1
● starting while the engine is running is prevented.
2
If the touch start function is programmed, a short start command with the ignition key in position 2 or a start button, if available, suffices.
with cold starting device ● Insert key. – Position 0 = no operating voltage. ● Turn key to the right. – Position 1 = operating voltage. – Engine is ready for operation. ● Below the temperature specified in the electronic engine control, the pre-heating phase begins with turning on the ignition. ● The electronic engine control controls and activates the current feed to the glow plugs via the engine coolant temperatures. ● Push the key in and turn further clockwise against spring pressure. – Level 2 = start. ● release the key as soon as the engine starts up. – The pilot lamps will go out. If the starter is controlled by the electronic engine
