Fuel/Lubrication/ Cooling
3. Remove the storage compartment cover and storage compartment. Remove the air filter housing cover; then remove the air filter. Account for the air filter frame.
NOTE: Use new gaskets, lock nuts, and seals and lubricate all internal components when servicing the engine/transmission. SPECIAL TOOLS
A number of special tools must be available to the technician when performing service procedures in this section. Refer to the current Special Tools Catalog for the appropriate tool description. NOTE: When indicated for use, each special tool
will be identified by its specific name, as shown in the chart below, and capitalized. Description Oil Pressure Test Kit Seal Removal Tool Tachometer
FI467A
p/n 0644-495 0644-072 0644-275
NOTE: Special tools are available from the Service Department. TROUBLESHOOTING
1. Verify that the electric fuel pump is operating by listening for a “whirring” sound for several seconds after the ignition switch is turned to the ON position. If no sound can be heard, see Electrical System - EFI Sensors/Components.
FI468A
2. Check for a flashing DTC (Diagnostic Trouble Code) on the LCD. If a code is flashing, see EFI Sensors/Components in Electrical System. 3. Make sure there is sufficient, clean gas in the gas tank.
Throttle Body ! WARNING Whenever any maintenance or inspection is performed on the fuel system during which there may be fuel leakage, there should be no welding, smoking, open flames, etc., in the area.
FI705
4. Loosen the clamps securing the intake pipe which joins the air box to the throttle body boots; then remove the pipe.
REMOVING
1. Turn the ignition switch to the OFF position; then remove the ignition switch key.
! WARNING Do not turn the ignition switch to the ON position with the hoses removed and the battery connected. Gasoline will be pumped by the electric fuel pump causing a safety hazard.
2. Remove the seat and tool tray; then disconnect the battery. CF687A
83
