Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018
4.1.2
Assembly overview - Cooler/Radiator fan, model 1, Ibiza 2018, Arona
1 - Cowling 2 - Radiator mount support ❑ The radiator mounting will be reused when re‐ installing the radiator. It will then be bolted to the lock carrier. Bolts ⇒ Electronic Parts Cata‐ logue (ETKA) 3 - Condenser ❑ Removing and installing ⇒ Heating, air condi‐ tioning; Rep. gr. 87 ; Refrigerant circuit; Re‐ moving and installing condenser . 4 - Radiator for charge air cool‐ ing circuit ❑ Removing and installing ⇒ “4.4.2 Removing and installing water radiator for charge air cooling circuit, Ibiza 2018, Aro‐ na”, page 329 5 - Coolant hose ❑ Pull out retaining clip to remove ❑ Connect ⇒ page 308 6 - O-ring ❑ byRenew Protected copyright. after Copyingremoval for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with 7 -respect Cowling to the correctness of information in this document. Copyright by SEAT S.A.
8 - Coolant hose ❑ Pull out retaining clip to remove ❑ Connect ⇒ page 308 9 - Bonded rubber bush ❑ For the charge-air cooler radiator 10 - Radiator for engine coolant ❑ Removing and installing ⇒ “4.3.2 Removing and installing radiator, Model 1, Arona, Ibiza 2018”, page 315 ❑ Renew coolant after replacing. 11 - Coolant hose ❑ Pull out retaining clip to remove ❑ Connect ⇒ page 308 12 - Retaining clip 13 - O-ring ❑ Renew after removal 14 - Radiator outlet coolant temperature sender - G83❑ Removing and installing ⇒ “2.9.2 Removing and installing radiator outlet coolant temperature sender G83 , Ibiza 2018, Arona”, page 299 4. Radiator, radiator fan
307
