Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 •
Thickness of sealant bead: 2 ... 3 mm
•
run along inner side of bolt holes -arrows-. Note
♦ Apply the sealant bead with particular care around the sealing
flange.
♦ The sump must be installed within 5 minutes after applying the
sealant.
– Position oil sump and tighten bolts . ⇒ page 235 – Install oil filter ⇒ page 254 . Note
Allow sealant to cure for approx. minutes afterpurposes, installing Protected by copyright. Copying for30 private or commercial in partlower or in whole, is not permitted unlessthen authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with part of sump. Only fill with engine oil. respect to the correctness of information in this document. Copyright by SEAT S.A.
– Fill with engine oil and check oil level ⇒ “1.2 Engine oil:”, page 237 . Note
The oil level must not be above the max. marking on the dipstick - danger of damage to the catalytic converter! Specified torques ♦ Securing bolts for air conditioner compressor ⇒ Heating, air conditioning system; Rep. gr. 87 ; Air conditioner compressor; Removing and installing air conditioner compressor ♦ ⇒ “1.1 Assembly overview - sump/oil pump”, page 233 ♦ ⇒ General body repairs, exterior; Rep. gr. 66 ; Noise insula‐ tion; Assembly overview - noise insulation ♦ Noise insulation assembly bolts, Toledo 213, Ibiza 2016 ⇒ General body works, exterior; Rep. gr. 50 ; Underbody pro‐ tection; Assembly overview: underbody protection
1.4
Removing and installing oil pump
Removing – Remove alternator ⇒ Electrical system; Rep. gr. 27 ; Alter‐ nator; Removing and installing alternator . – Remove toothed belt ⇒ “2.3 Removing and installing toothed belt”, page 176 . – Remove sump ⇒ “1.3 Removing and installing sump”, page 237 . – Remove the seal ⇒ “1.6 Renewing crankshaft oil seal - belt pulley end”, page 132 .
242
Rep. gr.17 - Lubrication
