2016 Seat Ibiza Workshop Manual - PDF DOWNLOAD

Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 – To do this, turn camshafts with adapter for angle sensor - VAS 611 007/5- -E-. – Hold camshafts via adapter for angle sensor - VAS 611 007/9and adapter for angle sensor - VAS 611 007/10- -E- in 0.0° position with a wrench. Note ♦ The camshafts tend to turn. ♦ Use a hexagon key to hold the camshafts in 0.0° position. ♦ Always remove the hexagon key after the camshafts have

been tightened.

– Tighten brakes after adjustment has been completed. – Tighten bolts -a- for brakes to 11 Nm on both sides. – Make sure that brake indicator on display is red -C-. •

It must not be yellow or green.

– Unscrew locking pin - T10340- -A-. – Tighten intake camshaft adjusted using pre-tension procedure ⇒ “3.4.1 Removing and installing camshaft adjuster for inlet camshaft”, page 211 . – Tighten camshaft adjuster on exhaust camshaft to specified initial torque ⇒ “3.4.2 Removing and installing camshaft adjuster for ex‐ haust camshaft”, page 215 .

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.

192

Rep. gr.15 - Cylinder head, valve gear
